HL500

The BIOTEKNIX HL500 HOTEL LOCK is a smart RFID-based electronic hotel locking system designed to provide secure, efficient, and modern room access management for hotels, resorts, serviced apartments, and hospitality environments. Built with advanced RFID technology and a durable electro-mechanical locking mechanism, the system enhances guest convenience while ensuring reliable room security and professional hotel operations. Designed with premium-grade stainless steel construction and elegant finishing, the BIOTEKNIX HL500 HOTEL LOCK delivers long-lasting durability, smooth performance, and modern aesthetics suitable for contemporary hospitality interiors. The lock supports contactless MIFARE card authentication, allowing fast and secure room access for guests and authorized hotel staff.

Datasheet

share the website to

parameters

Power Supply 4xAA alkaline battery
Material Aluminum alloy
Metal Finishes Coffee Gold
Mortise EURO profile, 60mm backset
Emergency Opening Options Emergency Opening with Mechanical cylinder
Locking Mechanism Electro-mechanical locking mechanism
Door Thickness Standard 40mm-50mm
Customized Structure Used for 30mm or below 30mm
Working Temperature -20°-60°
RFID Specification 13.56MHZ Technology
Features * Compatible with ISO 14443 A standard
* Simple Offline installation
* High Security with 302 stainless steel through advanced hardened high resistance anti-drill plates.
* Fully integrated with the Flock hotel locking Platform
* All Communication between the carrier and the electronic lock are encrypted and secure
* Optical signaling through LED .Dual color blue/red to indicate access authorization
* Battery Operated 4xLR6 Size AA
* 1700 access events can be audited
* Euro profile emergency opening by mechanical override
* High strength stainless steel mortise latches
